# Anjin [![openupm](https://camo.githubusercontent.com/3b330244da0d9f69418bd1d6fb033f03402a4f3aaae948e26a0405d8ba590579/68747470733a2f2f696d672e736869656c64732e696f2f6e706d2f762f636f6d2e64656e612e616e6a696e3f6c6162656c3d6f70656e75706d2672656769737472795f7572693d68747470733a2f2f7061636b6167652e6f70656e75706d2e636f6d)](https://openupm.com/packages/com.dena.anjin/) Click [日本語](https://github.com/DeNA/Anjin/blob/master/README_ja.md) for the Japanese page if you need. **Anjin** is an autopilot framework for games made with Unity. It consists of the following two elements. 1. A dispatcher that launches the corresponding Agent according to the Scene loaded in the game 2. An Agent that realizes auto-execution closed to the Scene Agents are small, isolated C# scripts that perform specific operations, such as playback of UI operations or monkey tests. In addition to the built-in ones, you can implement and use ones specific to your game title. ## Installation You can choose from two typical installation methods. ### Install via Package Manager window 1. Open the **Package Manager** tab in Project Settings window (**Editor > Project Settings**) 2. Click **+** button under the **Scoped Registries** and enter the following settings (figure 1.): 1. **Name:** `package.openupm.com` 2. **URL:** `https://package.openupm.com` 3. **Scope(s):** `com.dena`, `com.cysharp`, and `com.nowsprinting` 3. Open the Package Manager window (**Window > Package Manager**) and select **My Registries** in registries drop-down list (figure 2.) 4. Click **Install** button on the `com.dena.anjin` package **Figure 1.** Package Manager tab in Project Settings window. ![](https://github.com/DeNA/Anjin/raw/master/Documentation~/ProjectSettings_Dark.png#gh-dark-mode-only) ![](https://github.com/DeNA/Anjin/raw/master/Documentation~/ProjectSettings_Light.png#gh-light-mode-only) **Figure 2.** Select registries drop-down list in Package Manager window. ![](https://github.com/DeNA/Anjin/raw/master/Documentation~/PackageManager_Dark.png#gh-dark-mode-only) ![](https://github.com/DeNA/Anjin/raw/master/Documentation~/PackageManager_Light.png#gh-light-mode-only) > [!NOTE] > Do not forget to add `com.cysharp` and `com.nowsprinting` into scopes. These are used within Anjin. > [!NOTE] > Required install [Unity Test Framework](https://docs.unity3d.com/Packages/com.unity.test-framework@latest) package v1.3 or later for running tests (when adding to the `testables` in package.json). ### Install via OpenUPM-CLI If you installed [openupm-cli](https://github.com/openupm/openupm-cli), run the command below: ```bash openupm add com.dena.anjin ``` `UNITY_INCLUDE_TESTS || DENA_AUTOPILOT_ENABLE` is set in the Define Constraints of the Assembly Definition File, So excluded from the release build in principle. ### Recommended .gitignore The following files are automatically generated when you start Anjin. There is no need to track it, so we recommend adding it to your project's .gitignore file (or ignore settings of using VCS). ``` /[Aa]ssets/[Aa]utopilot[Ss]tate.asset* ``` And, the following files will be generated if you use the Automated QA package. We recommend ignoring these as well. ``` /[Aa]ssets/[Aa]utomated[Qq][Aa]* /[Aa]ssets/[Rr]ecordings* ``` ## Settings for game title After installing the UPM package in the game title Unity project, configure and implement the following. - Generate and configure the AutopilotSettings.asset file - Generate and configure the .asset file for the Agent to be used - Implement a custom Agent if necessary - Implement initialization process as needed > [!NOTE] > Set `UNITY_INCLUDE_TESTS || DENA_AUTOPILOT_ENABLE` in the Define Constraints of the Assembly Definition File to which they belong to exclude them from release builds. ### Generate and configure the AutopilotSettings.asset file Right-click in the Unity Editor's Project window to open the context menu, then select **Create > Anjin > Autopilot Settings** to create the file. The file name is arbitrary, and multiple files can be created and used within a project. There are three main settings. #### Agent Assignment ##### Scene Agent Mapping and Fallback Agent Set up a mapping of Agent configuration files (.asset) to be automatically executed for each Scene. Set the combination of `Scene` and `Agent`. The order does not affect the operation. If a Scene does not exist in the list, the Agent set in `Fallback Agent` will be used. For example, if you want `UGUIMonkeyAgent` to work for all Scenes, set `Scene Agent Maps` to empty, and set Set the `Fallback Agent` to an `UGUIMonkeyAgent`'s .asset file. ##### Scene Crossing Agents Set the Agents to run by scene crossing, independent of `Scene Agent Maps` and `Fallback Agent`. The specified agents will have the same lifespan as Autopilot (i.e., use `DontDestroyOnLoad`) for specifying, e.g., `ErrorHandlerAgent` and `UGUIEmergencyExitAgent`. > [!WARNING] > Recommend set an [ErrorHandlerAgent](https://github.com/DeNA/Anjin/raw/master/#ErrorHandlerAgent) to interrupt Autopilot if an exception occurs during execution. #### Autopilot Lifespan Settings

Lifespan: Specifies the execution time limit in seconds. Defaults to 300 seconds, 0 specifies unlimited operation. This item can also be overridden from the command line (see below).
Exit Code: Select the exit code used when Autopilot lifespan expires.
Custom Exit Code: Specify the exit code as an integer value.
Message: Message sent by the Reporter when Autopilot lifespan expires.

#### Autopilot Run Settings

Random Seed: Specify when you want to fix the seed given to the pseudo-random number generator (optional). This is a setting related to the pseudo-random number generator used by the autopilot. To fix the seed of the pseudo-random number generator in the game itself, it is necessary to implement this setting on the game title side. This item can also be overridden from the command line (see below).
Time Scale: Time.timeScale. Default is 1.0. This item can also be overridden from the command line (see below).
Output Root Path: Output files root directory path used by Agents, Loggers, and Reporters. When a relative path is specified, the origin is the project root in the Editor, and Application.persistentDataPath on the Player. This item can also be overridden from the command line (see below).
Screenshots Path: Screenshots output directory path used by Agents. When a relative path is specified, relative to the outputRootPath. This item can also be overridden from the command line (see below).
Clean Screenshots: Clean screenshots under screenshotsPath when launching Autopilot.
Loggers: Logger used for this autopilot settings. If omitted, Debug.unityLogger will be used as default.
Reporters: Reporter to be called on Autopilot terminate.

### Generate and configure the Agent setting file (.asset) Whether you use the built-in Agent or implement custom Agent, you must create an instance (.asset file) of it in the Unity editor. Instances are created by right-clicking in the Project window of the Unity editor to open the context menu, then selecting **Create > Anjin > Agent type name**. Select the generated file, Agent-specific settings are displayed in the inspector and can be customized. You can prepare multiple Agents with different settings for the same Agent type and use them in different Scenes. ### Generate and configure the Logger setting file (.asset) Logger instances are created by right-clicking in the Project window of the Unity editor to open the context menu, then selecting **Create > Anjin > Logger type name**. Select the generated file, Logger-specific settings are displayed in the inspector and can be customized. You can prepare multiple Loggers with different settings for the same Logger type. ### Generate and configure the Reporter setting file (.asset) Reporter instances are created by right-clicking in the Project window of the Unity editor to open the context menu, then selecting **Create > Anjin > Reporter type name**. Select the generated file, Reporter-specific settings are displayed in the inspector and can be customized. You can prepare multiple Reporters with different settings for the same Reporter type. ## Run autopilot Autopilot can be run in the Unity editor in three ways. ### 1. Run on play mode in Unity editor (GUI) Open the AutopilotSettings file you wish to run in the inspector and click the **Run** button to launch Autopilot. After the set run time has elapsed, or as in normal play mode, clicking the Play button will stop the program. > [!TIP] > If you start the Autopilot in Edit Mode, so return to Edit Mode when the Autopilot is terminated. > If you start the Autopilot in Play Mode, Play Mode will continue even after the autopilot is terminated. ### 2. Launch from command line To launch from the command line, specify the following arguments. ```bash $(UNITY) \ -projectPath $(PROJECT_HOME) \ -batchmode \ -executeMethod DeNA.Anjin.Editor.Commandline.Bootstrap \ -AUTOPILOT_SETTINGS Assets/Path/To/AutopilotSettings.asset ``` - `UNITY` is the path to the Unity editor, and `PROJECT_HOME` is the root of the project to be autorun. - `-AUTOPILOT_SETTINGS` is the path to the settings file (AutopilotSettings) you want to run. - Do not specify `-quit` (it will exit without entering play mode). - Do not specify `-nographics` (do not show GameView window). In addition, some settings can be overridden by adding the following arguments. For details on each argument, see the entry of the same name in the "Generate and configure the AutopilotSettings.asset file" mentioned above. In both cases, the key should be prefixed with `-` and specified as `-LIFESPAN_SEC 60`.

LIFESPAN_SEC: Specifies the execution time limit in seconds
RANDOM_SEED: Specifies when you want to fix the seed given to the pseudo-random number generator
TIME_SCALE: Specifies the Time.timeScale. Default is 1.0
OUTPUT_ROOT_DIRECTORY_PATH: Output files root directory path used by Agents, Loggers, and Reporters.
SCREENSHOTS_DIRECTORY_PATH: Screenshots output directory path used by Agents.

The following arguments are only valid when launching the Unity Editor and Anjin from the command line.

GAME_VIEW_WIDTH: Set GameView width. This argument is only used to launch in editor from command line. Default is 640.
GAME_VIEW_HEIGHT: Set GameView height. This argument is only used to launch in editor from command line. Default is 480.

> [!IMPORTANT] > Shown GameView window even in batchmode. > We have confirmed that it works with Xvfb, but since Unity does not officially support it, it may not be available in the future. ### 3. Run in Play Mode tests Autopilot works within your test code using the static method `Launcher.LaunchAutopilotAsync(string)`. Specify the `AutopilotSettings` file path via the argument. ``` [Test] public async Task LaunchAutopilotInTest() { // Load the first scene (required scene in "Scenes in Build") await SceneManager.LoadSceneAsync("Title"); // Launch autopilot await Launcher.LaunchAutopilotAsync("Assets/Path/To/AutopilotSettings.asset"); } ``` > [!WARNING] > The default timeout for tests is 3 minutes. If the autopilot execution time exceeds 3 minutes, please specify the timeout time with the `Timeout` attribute. > [!WARNING] > When running tests on a player, any necessary configuration files must be placed in the `Resources` folder to be included in the player build. It can use `IPrebuildSetup` and `IPostBuildCleanup` to insert processing into the test player build. > The file path is specified relative to the `Resources` folder without the extension (".asset"). > [!NOTE] > The test will fail if the test-runner detects a `LogException` or `LogError` output. You can suppress this by using `LogAssert.ignoreFailingMessages` assuming that you will use Anjin for error handling. > [!NOTE] > If running multiple scenarios in succession, you can preserve the output files by specifying different paths in `AutopilotSettings.outputRootPath`. ## Built-in Agents The following Agent types are provided. These can be used as they are, or game-title-specific custom Agents can be implemented and used. ### UGUIMonkeyAgent This is an Agent that randomly manipulates uGUI components. This Agent implementation uses open source [Monkey Test Helper](https://github.com/nowsprinting/test-helper.monkey) package. An instance of this Agent (.asset file) can contain the following.

Lifespan: Duration of random operation execution time in secounds. If 0 is specified, the operation is almost unlimited (TimeSpan.MaxValue). With this setting, neither Autopilot nor the app itself will exit when the Agent exits. It will not do anything until the next Scene switch
Delay: Wait interval [milliseconds] between random operations
No-Element Timeout: Abort Autopilot when the interactable UI/ 2D/ 3D element does not appear for the specified seconds. Disable detection if set to 0.
Repeating Operation Detection Buffer Length: Abort Autopilot when repeating operation is detected within the specified buffer length. For example, if the buffer length is 10, repeating 5-step sequences can be detected. Disable detection if set to 0.
Enable Gizmos: Show Gizmos on GameView during running monkey test if true

#### Screenshot Options

Enabled: Whether screenshot is enabled or not
Filename: Use Default: Whether using a default prefix of screenshots filename or specifying it manually. Default value is Agent name
Prefix: Prefix of screenshots filename
Super Size: The factor to increase resolution with. Neither this nor Stereo Capture Mode can be specified
Stereo Capture Mode: The eye texture to capture when stereo rendering is enabled. Neither this nor Resolution Factor can be specified

#### Click and Hold Operator Options

Click and Hold Millis: Delay time for click-and-hold [ms]

#### Text Input Operator Options

GameObject Name: Target GameObject name. If it is difficult to identify the GameObject by name, you can also use InputFieldAnnotation, which will be described later.
Characters Kind: Type of characters to be entered in the InputField. The options are "Printable", "Alphanumeric", and "Digits".
Minimum Length: Minimum number of characters that can be entered into the InputField.
Maximum Length: Maximum number of characters that can be entered into the InputField.

> [!TIP] > If you have a `GameObject` that you want to avoid manipulation by the `UGUIMonkeyAgent`, attach the `IgnoreAnnotation` component in the `TestHelper.Monkey.Annotations` assembly. > See **Anjin Annotations** below for more information. ### UGUIPlaybackAgent This is an Agent that playback uGUI operations with the Recorded Playback feature of the [Automated QA](https://docs.unity3d.com/Packages/com.unity.automated-testing@latest) package. The following can be set in an instance (.asset file) of this Agent.

Recorded JSON file: JSON file recorded by AutomatedQA package.

Use the Recorded Playback window for recording operations with Automated QA. The window is opened via the Unity editor menu **Automated QA > Automated QA Hub > Recorded Playback**. The recording file (.json) is saved under the Assets/Recordings/ folder and can be freely moved or renamed. Note that the Recorded Playback function in Automated QA can record operations across Scene transitions, but in Anjin, when the Scene is switched, the Agent is also forcibly switched, so playback is also interrupted. Therefore, please be careful to record in units of Scenes. > [!IMPORTANT] > The Automated QA package outputs `LogType.Error` to the console when playback fails (e.g., the target Button cannot be found). The following setting is required to detect this and terminate the autopilot. > 1. Add [ErrorHandlerAgent](https://github.com/DeNA/Anjin/raw/master/#ErrorHandlerAgent) and set `Handle Error` to `Terminate Autopilot`. > 2. Add [ConsoleLogger](https://github.com/DeNA/Anjin/raw/master/#ConsoleLogger) and set `Filter LogType` to `Error` or higher. > [!IMPORTANT] > The Automated QA package is in the preview stage. Please note that destructive changes may occur, and the package itself may be discontinued or withdrawn. ### DoNothingAgent An Agent that does nothing. The following settings can be configured for this Agent instance (.asset file).

Lifespan: Specifies the do nothing time in seconds. 0 means unlimited time to do nothing. If 0 is specified, an unlimited amount of time for no action is taken. It will not do anything until the next Scene is switched.

### TerminateAgent Terminates the Autopilot running. It is intended to be executed after the goal of a test scenario is achieved. The following settings can be configured for this Agent instance (.asset file).

Exit Code: Select the exit code used when this agent terminates the Autopilot.
Custom Exit Code: Input exit code by integer value.
Message: Message sent by the Reporter when this agent terminates the Autopilot.

### ParallelCompositeAgent An Agent that executes multiple Agents in parallel. The instance of this Agent (.asset file) can have the following settings.

Agents: A list of Agents to be executed in parallel, which can be nested by specifying a CompositeAgent

### SerialCompositeAgent An Agent that executes multiple Agents in series. The instance of this Agent (.asset file) can have the following settings.

Agents: A list of Agents to be executed in series, which can be nested by specifying a CompositeAgent

### OneTimeAgent An Agent that can register one child Agent and execute it only once throughout the Autopilot execution period. The second time executions will be skipped. For example, in a game where the title scene leads to a different path only for the first time or where the user receives a login bonus only for the first time on the home scene, it is possible to construct a test scenario in which the title screen is executed as is even if a communication error or the like causes a return to the title scene. The Agent instance (.asset file) can contain the following settings.

Agent: Agent that can be executed only once, which can be nested by specifying a CompositeAgent

### RepeatAgent An Agent that executes one child Agent indefinitely and repeatedly. Combined with SerialCompositeAgent, it can be used to repeat a sequence many times or to repeat a specific Agent. Note that finite iterations are not supported (to use SerialCompositeAgent). This Agent instance (.asset file) can contain the following.

Agent: Agent to be executed repeatedly, which can be nested by specifying a CompositeAgent

### TimeBombAgent An Agent that will fail if a defuse message is not received before the inner Agent exits. For example, pass the out-game tutorial (Things that can be completed with tap operations on uGUI, such as smartphone games). 1. Set `UGUIMonkeyAgent` as the `Agent`. It should not be able to operate except for the advancing button. Set the `Lifespan Sec` with a little margin. 2. Set the log message to be output when the tutorial is completed as the `Defuse Message`. This Agent instance (.asset file) can contain the following.

Agent: Working Agent. If this Agent exits first, the TimeBombAgent will fail.
Defuse Message: Defuse the time bomb when this message comes to the log first. Regex is also available.

### ErrorHandlerAgent An Agent that detects abnormal log messages and terminates the Autopilot running. It should always be started at the same time as other Agents (that actually perform game operations). Generally, you add to `Scene Crossing Agents` in `AutopilotSettings`. If you want to change the settings for each Scene, use with `ParallelCompositeAgent`. This Agent instance (.asset file) can contain the following.

Handle Exception: Specify an Autopilot terminates or only reports when an Exception is detected in the log. It can be overwritten with the command line argument -HANDLE_EXCEPTION, but be careful if multiple ErrorHandlerAgents are defined, they will all be overwritten with the same value.
Handle Error: Specify an Autopilot terminates or only reports when an Error is detected in the log. It can be overwritten with the command line argument -HANDLE_ERROR, but be careful if multiple ErrorHandlerAgents are defined, they will all be overwritten with the same value.
Handle Assert: Specify an Autopilot terminates or only reports when an Assert is detected in the log. It can be overwritten with the command line argument -HANDLE_ASSERT, but be careful if multiple ErrorHandlerAgents are defined, they will all be overwritten with the same value.
Handle Warning: Specify an Autopilot terminates or only reports when an Warning is detected in the log. It can be overwritten with the command line argument -HANDLE_WARNING, but be careful if multiple ErrorHandlerAgents are defined, they will all be overwritten with the same value.
Ignore Messages: Log messages containing the specified strings will be ignored from the stop condition. Regex is also available; escape is a single backslash (`\`).

> [!TIP] > Recommend enabling a `Handle Exception` to interrupt Autopilot if an exception occurs during execution. ### UGUIEmergencyExitAgent An Agent that monitors the appearance of the `EmergencyExitAnnotations` component in the Scene and clicks on it as soon as it appears. This can be used in games that contain behavior that is irregular in the execution of the test scenario, for example, communication errors or "Return to Title Screen" buttons that are triggered by a daybreak. It should always be started at the same time as other Agents (that actually perform game operations). Generally, you add to `Scene Crossing Agents` in `AutopilotSettings`. If you want to change the settings for each Scene, use with `ParallelCompositeAgent`. This Agent instance (.asset file) can contain the following.

Interval: Interval in milliseconds to check for the appearance of the EmergencyExitAnnotation component.
Screenshot: Take a screenshot when click the EmergencyExit button.

## Built-in Loggers The following Logger types are provided. These can be used as they are, or game-title-specific custom Loggers can be implemented and used. ### ConsoleLogger A Logger that outputs to a console. The instance of this Logger (.asset file) can have the following settings.

Filter LogType: To selective enable debug log message

### FileLogger A Logger that outputs to a specified file. The instance of this Logger (.asset file) can have the following settings.

Output File Path: Output path for log file path. When a relative path is specified, relative to the AutopilotSettings.outputRootPath. It can be overwritten with the command line argument -FILE_LOGGER_OUTPUT_PATH, but be careful if multiple FileLoggers are defined, they will all be overwritten with the same value.
Filter LogType: To selective enable debug log message
Timestamp: Output timestamp to log entities

## Built-in Reporters The following Reporter types are provided. These can be used as they are, or game-title-specific custom Reporters can be implemented and used. ### JUnitXmlReporter A reporter that outputs report files in JUnit XML format. If there are zero errors and zero failures, the autopilot run is considered to have completed successfully. The instance of this Reporter (.asset file) can have the following settings.

Output File Path: Output path for JUnit XML format file. When a relative path is specified, relative to the AutopilotSettings.outputRootPath. It can be overwritten with the command line argument -JUNIT_REPORT_PATH, but be careful if multiple JUnitXmlReporters are defined, they will all be overwritten with the same value.

### SlackReporter A Reporter that post report to Slack. The instance of this Reporter (.asset file) can have the following settings.

Slack Token: Slack Bot OAuth token. If omitted, it will not be sent. It can be overwritten with the command line argument -SLACK_TOKEN, but be careful if multiple SlackReporters are defined, they will all be overwritten with the same value.
Slack Channels: Comma-separated Slack channel name (e.g., "#test") or ID (e.g., "C123456") to post. If omitted, it will not be sent. Note that the bot must be invited to the channel. It can be overwritten with the command line argument -SLACK_CHANNELS, but be careful if multiple SlackReporters are defined, they will all be overwritten with the same value.
Mention User Group IDs: Comma-separated user group IDs to mention when posting error reports.
Add @here: Add @here to the post when posting error reports.
Lead Text: Lead text for error reports. It is used in OS notifications. You can specify placeholders like a "{message}".
Message: Message body template for error reports. You can specify placeholders like a "{message}".
Color: Attachments color for error reports. Default color is same as Slack's "danger" red.
Screenshot: Take a screenshot for error reports. Default is on.
Post on Completion: Also post a report if completed autopilot normally. Default is off.

You can create a Slack Bot on the following page: [Slack API: Applications](https://api.slack.com/apps) The Slack Bot needs the following permissions: - chat:write - files:write The placeholders you can include in the lead and message body template are: - "{message}": Message with terminate (e.g., error log message) - "{settings}": Name of running AutopilotSettings - "{env.KEY}": Environment variables - "{mppm-tags}": Tags of the [Multiplayer Play Mode](https://docs.unity3d.com/Packages/com.unity.multiplayer.playmode@latest) package ## Implementation of game-title-specific Game-title-specific custom Agents and initialization code must be avoided in the release build. Create a unique assembly and turn off "Auto Referenced", and set the "Define Constraints" to `UNITY_INCLUDE_TESTS || DENA_AUTOPILOT_ENABLE`. This asmdef and its storage folder can be created by opening the context menu anywhere in the Project window and selecting **Create > Anjin > Game Title Specific Assembly Folder**. ### Game-title-specific initialization process If your game title requires its specific initialization process, add the `InitializeOnLaunchAutopilot` attribute to the static method that does the initialization. An added method is called from the autopilot launch process. ```csharp [InitializeOnLaunchAutopilot] public static void InitializeOnLaunchAutopilotMethod() { // initialize code for your game. } ``` Async methods are also supported. ```csharp [InitializeOnLaunchAutopilot] private static async UniTask InitializeOnLaunchAutopilotMethodAsync() { // initialize code for your game. } ``` > [!NOTE] > You can specify callback order with argument. Callbacks with lower values are called before ones with higher values. > [!NOTE] > The autopilot launch process is performed with `RuntimeInitializeOnLoadMethod(RuntimeInitializeLoadType.AfterSceneLoad)` (default for `RuntimeInitializeOnLoadMethod`). > Also, `RuntimeInitializeOnLoadMethod(RuntimeInitializeLoadType.SubsystemRegistration)` implements the initialization process for Configurable Enter Play Mode. ### Custom Agents A custom Agent is created by inheriting from `Anjin.Agents.AbstractAgent`. Simply implement the process to be executed by the Agent in the method `UniTask Run()`. The following fields defined in `AbstractAgent` are available. Each instance is set before calling the `Run` method. - `Logger`: Implementation of `UnityEngine.ILogger` specified in AutopilotSettings. Use this if you want to log output in Agent. - `Random`: Implementation of `Anjin.Utilities.IRandom`. Which is created from a seed specified in AutopilotSettings or a startup argument. Note that it is convenient to set the `[CreateAssetMenu]` attribute to create an instance from the context menu. ### Custom Loggers A custom Logger is created by inheriting from `Anjin.Logers.AbstractLoggerAsset`. You must implement the `Logger { get; }` property to return custom `UnityEngine.ILogger` implementation. Note that it is convenient to set the `[CreateAssetMenu]` attribute to create an instance from the context menu. ### Custom Reporters A custom Reporter is created by inheriting from `Anjin.Reporters.AbstractReporter`. Simply implement the method `UniTask PostReportAsync()`. Note that it is convenient to set the `[CreateAssetMenu]` attribute to create an instance from the context menu. ## Anjin Annotations Annotations are defined to control Anjin operations. Use the `DeNA.Anjin.Annotations` assembly by adding it to the Assembly Definition References. Please note that this will be included in the release build due to the way it works. > [!NOTE] > Even if the annotations assembly is removed from the release build, the link to the annotation component will remain Scenes and Prefabs in the asset bundle built. > Therefore, a warning log will be output during instantiate. > To avoid this, annotations assembly are included in release builds. ### IgnoreAnnotation The `GameObject` to which this component is attached avoids manipulation by the `UGUIMonkeyAgent`. ### EmergencyExitAnnotations When a `Button` to which this component is attached appears, the `UGUIEmergencyExitAgent` will immediately attempt to click on it. It is intended to be attached to buttons that are irregular in the execution of the test scenario, such as the "return to title screen" button due to a communication error or a daybreak. ## Using with Multiplayer Play Mode package It is now easy to check the operation of multiplayer games by using the [Multiplayer Play Mode](https://docs.unity3d.com/Packages/com.unity.multiplayer.playmode@latest) (MPPM) package, which is available in Unity 6 and later. Below are some points to note when using Anjin with the MPPM package. This has been checked with MPPM package v1.3.1. ### Run on Virtual Players When running in [Virtual Players](https://docs-multiplayer.unity3d.com/mppm/current/virtual-players/), clicking the **Run** button in the AutopilotSettings file in Edit Mode will launch the Autopilot in all Virtual Players. Launching in Play Mode or using different AutopilotSettings for different players is impossible. To specify different behaviors for different players, you will need to implement a custom Agent that branches based on [tags](https://docs-multiplayer.unity3d.com/mppm/current/player-tags/). When you specify a relative path for the "Output Root Path" of AutopilotSettings, the base will be the directory of each Virtual Player. Therefore, each Virtual Player's output of Agents, Loggers, and Reporters will be preserved. > [!CAUTION] > The Automated QA package that `UGUIPlaybackAgent` depends on writes its output files to `Application.persistentDataPath`. > Because all the Virtual Players try to write to the same file, an error is printed to the console. > [!WARNING] > Files under Assets are shared with Virtual Players via symbolic links. > Therefore, when you change settings in the Inspector, you must save them using the menu item **File > Save (command + S)** before re-running Autopilot. ### Run on Play Mode Scenarios To run in [Play Mode Scenarios](https://docs-multiplayer.unity3d.com/mppm/current/play-mode-scenario/play-mode-scenario-about/), you will need a player build that includes Anjin. For instructions on how to build it, see [Run on player build](https://github.com/DeNA/Anjin/raw/master/#run-on-player-build-experimental). Play Mode Scenarios can be launched with command line arguments for each player, allowing them to use different AutopilotSettings files. > [!CAUTION] > The Automated QA package that `UGUIPlaybackAgent` depends on writes its output files to `Application.persistentDataPath`. > Because all the Virtual Players try to write to the same file, an error is printed to the console. ## Run on player build \[experimental\] It can run autopilot on the players (real devices) if Anjin is included in player builds. > [!WARNING] > This feature is experimental. > And Anjin itself is designed without much consideration for memory allocation, so please be careful when using it for performance testing. ### How to build #### 1. Set the custom scripting symbols `DENA_AUTOPILOT_ENABLE` and `COM_NOWSPRINTING_TEST_HELPER_ENABLE` Set a custom scripting symbols. See below: [Manual: Custom scripting symbols](https://docs.unity3d.com/Manual/custom-scripting-symbols.html) #### 2. Including configuration files into the player build Any necessary configuration files must be placed in the `Resources` folder to be included in the player build. It can use `IPreprocessBuildWithReport` and `IPostprocessBuildWithReport` to insert processing into the player build. #### 3. Exclude from iCloud backup (optional) Built-in File Logger and Agent screenshots are output under `Application.persistentDataPath` when running the player. This path is included in iCloud backup by default, so exclude it if not required. ```csharp UnityEngine.iOS.Device.SetNoBackupFlag(Application.persistentDataPath); ``` #### 4. Add a launch autopilot button to the debug menu (optional) e.g., Launch autopilot with [UnityDebugSheet](https://github.com/Haruma-K/UnityDebugSheet): ```csharp AddButton("Launch autopilot", clicked: () => { _drawerController.SetStateWithAnimation(DrawerState.Min); // close debug menu before launch autopilot #if UNITY_EDITOR const string Path = "Assets/Path/To/AutopilotSettings.asset"; #else const string Path = "Path/To/AutopilotSettings"; // relative path from Resources and without the .asset extension. #endif Launcher.LaunchAutopilotAsync(Path).Forget(); }); ``` > [!NOTE] > `Launcher.LaunchAutopilotAsync` can also use an overload that passes an `AutopilotSettings` instance as an argument. ### How to launch autopilot on player build It can also launch it using command line arguments, in addition to launching it from the debug menu. To execute from the command line, specify the following arguments. ```bash $(ROM) -LAUNCH_AUTOPILOT_SETTINGS Path/To/AutopilotSettings ``` - `ROM` is the path to the player build executable file. - `-LAUNCH_AUTOPILOT_SETTINGS` is the path to the settings file (AutopilotSettings) you want to run. Path is relative to the `Resources` folder and without the `.asset` extension. It can specify the same arguments as when running in the editor. > [!NOTE] > Built-in File Logger and Agent screenshots are output under `Application.persistentDataPath` when running the player. > See below for each platform: > [Application.persistentDataPath](https://docs.unity3d.com/ScriptReference/Application-persistentDataPath.html) > [!NOTE] > Android has a different way of specifying command line arguments. See below: > [Manual: Specify Android Player command-line arguments](https://docs.unity3d.com/Manual/android-custom-activity-command-line.html) ## Troubleshooting ### Autopilot is stopped, but the Run button in AutopilotSettings does not appear The `AutopilotState.asset` that persists in Anjin's execution state may be in an incorrect state. Open it in the inspector and click the **Reset** button. If this does not solve the problem, try deleting `AutopilotState.asset`. ### Autopilot runs on its own in play mode The `AutopilotState.asset` that persists in Anjin's execution state may be in an incorrect state. Open it in the inspector and click the **Reset** button. If this does not solve the problem, try deleting `AutopilotState.asset`. ### \[CompilerError\] Argument 1: Cannot convert to 'System.Threading.CancellationToken' The following compilation error has been reported in some cases: ``` [CompilerError] Argument 1:. Cannot convert from 'DeNA.Anjin.Reporters.SlackReporter.CoroutineRunner' to 'System.Threading.CancellationToken' Compiler Error at Library\PackageCache\com.dena.anjin@1.0.1\Runtime\Reporters\SlackReporter.cs:66 column 53 ``` This compile error occurs when using UniTask v2.3.0 or older. The `UniTask.WaitForEndOfFrame(MonoBehaviour)` API was implemented in UniTask v2.3.1 Usually, the correct version of UniTask is installed if you follow the installation instructions. However, if UniTask is placed as an embedded package in the project, it will be prioritized. Find out why you have an old UniTask installed. e.g., Check the contents of Packages/packages-lock.json generated by the Unity editor; use your IDE's code definition jump function to check where the source file of `UniTask.WaitForEndOfFrame()` is. ### Warning message "settings has been obsolete" when launch Autopilot For example, the following warning message may be output log. ``` Slack settings in AutopilotSettings has been obsolete. Now, automatically converted it to SlackReporter asset file. Check it out and commit it to your VCS. ``` This message that the obsolete setting item has been automatically converted to the new setting method (`SlackReporter` in the above example). The settings file has been updated, so please check it out and commit it to your VCS (e.g., Git). ## License MIT License ## How to contribute Open an issue or create a pull request. Be grateful if you could label the pull request as `enhancement`, `bug`, `chore`, and `documentation`. See [PR Labeler settings](https://github.com/DeNA/Anjin/raw/master/.github/pr-labeler.yml) for automatically labeling from the branch name. The general policy for accepting new features is as follows: - All built-in features can be easily configured in the Unity Editor's Inspector window. - Avoid adding features to the Autopilot class as much as possible, and consider expanding it with Agents, etc. - Refrain from adding non-general-purpose Agents, Loggers, and Reporters. Consider publishing them on your blog or Gist or placing them in Samples. The following feature requests/ pull requests will be rejected because they go against the concept of Anjin: - Ability to run multiple test scenarios (AutopilotSettings) in succession. Use the feature to run from Play Mode tests. - Ability to specify "Start Scene" in AutopilotSettings. We recommend creating a test scenario that can be run from any Scene. ## How to development Add this repository as a submodule to the Packages/ directory in your project. Run the command below: ```bash git submodule add https://github.com/dena/Anjin.git Packages/com.dena.anjin ``` > [!WARNING] > Required install packages for running tests (when adding to the `testables` in package.json), as follows: > - [Unity Test Framework](https://docs.unity3d.com/Packages/com.unity.test-framework@latest) package v1.4.1 or later > - [Test Helper](https://github.com/nowsprinting/test-helper) package v1.1.1 or later Generate a temporary project and run tests on each Unity version from the command line. ```bash make create_project UNITY_VERSION=2019.4.40f1 make -k test ``` > [!WARNING] > You must select "Input Manager (Old)" or "Both" in the **Project Settings > Player > Active Input Handling** for running tests. ## Release workflow Run **Actions > Create release pull request > Run workflow** and merge created pull request. (Or bump version in package.json on default branch) Then, Will do the release process automatically by [Release](https://github.com/DeNA/Anjin/raw/master/.github/workflows/release.yml) workflow. And after tagged, OpenUPM retrieves the tag and updates it. Do **NOT** manually operation the following operations: - Create release tag - Publish draft releases
