# TensorFlow Unreal Plugin [ badge

](https://www.unrealengine.com/en-US/blog/epic-megagrants-reaches-13-million-milestone-in-2019) [Unreal Engine](https://www.unrealengine.com) plugin for [TensorFlow](https://www.tensorflow.org/). Enables training and implementing state of the art [machine learning](https://en.wikipedia.org/wiki/Machine_learning) algorithms for your unreal projects. This plugin contains C++, Blueprint and python scripts that encapsulate TensorFlow operations as an _Actor Component_. It depends on an [UnrealEnginePython](https://github.com/getnamo/UnrealEnginePython) plugin fork and the [SocketIO Client](https://github.com/getnamo/socketio-client-ue4) plugin; these are always included in [binary releases](https://github.com/getnamo/TensorFlow-Unreal/releases) so no manual external downloading is necessary. See [Note on Dependencies section](https://github.com/getnamo/TensorFlow-Unreal#note-on-dependencies) for details on implementation and architecture. See [unreal forum thread](https://forums.unrealengine.com/community/work-in-progress/1357673-tensorflow) for discussions. ## Issues and Limitations There is currently only a working build for the Windows platform. Be careful where you place your project as you may hit [240 char filepath limit with your python dependencies](https://github.com/getnamo/TensorFlow-Unreal/issues/36). Near future refactor to open up dev environments and native support (WIP): https://github.com/getnamo/TensorFlow-Unreal/issues/53 - Machine Learning Remote - https://github.com/getnamo/MachineLearningRemote-Unreal - Tensorflow Native - Inference focused (WIP) https://github.com/getnamo/TensorFlowNative-Unreal Tensorflow UnrealEnginePython Platform Issues - [Linux issue#13 tracking](https://github.com/getnamo/TensorFlow-Unreal/issues/13) - [Android issue#11 tracking](https://github.com/getnamo/TensorFlow-Unreal/issues/11) - will likely be superceded by tf native - [Mac OS issue#10 tracking](https://github.com/getnamo/TensorFlow-Unreal/issues/10) - will likely be superceded by ml remote If you have ideas or fixes, consider contributing! See https://github.com/getnamo/TensorFlow-Unreal/issues for current issues. ## Installation & Setup 1. (GPU only) [Install CUDA and cudNN pre-requisites](https://www.tensorflow.org/install/gpu#windows_setup) if you're using compatible GPUs (NVIDIA) 2. [Download Latest Release](https://github.com/getnamo/TensorFlow-Unreal/releases) choose CPU or GPU download version if supported. 3. Create new or choose project. 4. Browse to your project folder (typically found at _Documents/Unreal Project/{Your Project Root}_) ![copy plugins](https://camo.githubusercontent.com/191ad378b406c609d8fb63189f5a03ca713f67132ad48824b0223a2b287ecf87/687474703a2f2f692e696d6775722e636f6d2f446b7472364a4b2e706e67) 5. Copy *Plugins* folder into your Project root. 6. Launch your project. 7. (Optional) All plugins should be enabled by default, you can confirm via Edit->Plugins. Scroll down to Project and you should see three plugins, TensorFlow in Computing, Socket.IO Client in Networking and UnrealEnginePython in Scripting Languages. Click Enabled if any is disabled and restart the Editor and open your project again. 8. Wait for tensorflow dependencies to be automatically installed. It will auto-resolve any dependencies listed in [Content/Scripts/upymodule.json](https://github.com/getnamo/TensorFlow-Unreal/raw/master/Content/Scripts/upymodule.json) using pip. Note that this step may take a few minutes and depends on your internet connection speed and you will see nothing in the output log window until it has fully completed. ![image](https://user-images.githubusercontent.com/542365/36981363-e88aa2ec-2084-11e8-828c-e5a526cda67b.png) 7. Once you see an output similar to this (specific packages will change with each version of tensorflow), the plugin is ready to use. ### Note on Git Cloning Using full [plugin binary releases](https://github.com/getnamo/TensorFlow-Unreal/releases) is recommended, this allows you to follow the [installation instructions as written](https://github.com/getnamo/TensorFlow-Unreal#installation--setup) and get up to speed quickly. If you instead wish to git clone and sync to master repository manually then it is expected that you [download the latest python binary dependency release](https://github.com/getnamo/UnrealEnginePython/releases) for UnrealEnginePython. This contains an embedded python build; select the *BinariesOnly-.7z* file from Downloads and drag the plugins folder into your project root. With that step complete, your clone repository should work as expected, all other dependencies will be pulled via pip on first launch. ## Examples [![mnist spawn samples](https://camo.githubusercontent.com/0e16520ae9e81ba688b25455517f2c08dd8621dc807377d26e69a31abaa7f99c/687474703a2f2f692e696d6775722e636f6d2f6b76734c5876462e676966)](https://github.com/getnamo/TensorFlow-Unreal-examples) *Basic MNIST softmax classifier trained on begin play with sample training inputs streamed to the editor during training. When fully trained, UTexture2D (1-3) samples are tested for prediction.* An example project is found at [https://github.com/getnamo/TensorFlow-Unreal-examples](https://github.com/getnamo/TensorFlow-Unreal-examples). The repository has basic examples for general tensorflow control and different mnist classification examples with UE4 UTexture2D input for prediction. The repository should expand as more plug and play examples are made. Consider contributing samples via pull requests! It is also the main repository where all development is tracked for all dependencies for this plugin. ## Python API You can either train directly or use a trained model inside UE4. To start, add your python script file to _{Project Root Folder}/Content/Scripts_. wrap your tensorflow python code by subclassing TFPluginAPI. #### MySubClass(TFPluginAPI) import ```tensorflow```, ```unreal_engine``` and ```TFPluginAPI``` in your module file and subclass the TFPluginAPI class with the following functions. ```python import tensorflow as tf import unreal_engine as ue from TFPluginAPI import TFPluginAPI class ExampleAPI(TFPluginAPI): #expected optional api: setup your model for training def onSetup(self): pass #expected optional api: parse input object and return a result object, which will be converted to json for UE4 def onJsonInput(self, jsonInput): result = {} return result #expected optional api: start training your network def onBeginTraining(self): pass #NOTE: this is a module function, not a class function. Change your CLASSNAME to reflect your class #required function to get our api def getApi(): #return CLASSNAME.getInstance() return ExampleAPI.getInstance() ``` Note the ```getApi()``` module function which needs to return a matching instance of your defined class. The rest of the functionality depends on what API you wish to use for your use case. At the moment the plugin supports input/output from UE4 via JSON encoding. If you wish to train in UE4, implement your logic in ```onBeginTraining()``` and ensure you check for ```self.shouldStop``` after each batch/epoch to handle early exit requests from the user e.g. when you _EndPlay_ or manually call ```StopTraining``` on the tensorflow component. You will also receive an optional ```onStopTraining``` callback when the user stops your training session. If you have a trained model, simply setup your model/load it from disk and omit the training function, and forward your evaluation/input via the ```onJsonInput(jsonArgs)``` callback. See [mnistSaveLoad.py example](https://github.com/getnamo/TensorFlow-Unreal-examples/raw/master/Content/Scripts/mnistSaveLoad.py) on how to train a network once, and then save the model, reloading it on setup such that you skip retraining it every time. Note that both ```onBeginTraining()``` and ```onSetup()``` are called asynchronously by default. If you use a high level library like e.g. keras, may need to store your *tf.Session* and *tf.Graph* separately and use it as default ```with self.session.as_default():``` and ```with self.graph.as_default():``` to evaluate, since all calls will be generally done in separate threads. Below is a very basic example of using tensorflow to add or subtract values passed in as ```{"a":, "b":}```. ```python import tensorflow as tf import unreal_engine as ue from TFPluginAPI import TFPluginAPI class ExampleAPI(TFPluginAPI): #expected optional api: setup your model for training def onSetup(self): self.sess = tf.InteractiveSession() self.a = tf.placeholder(tf.float32) self.b = tf.placeholder(tf.float32) #operation self.c = self.a + self.b pass #expected optional api: json input as a python object, get a and b values as a feed_dict def onJsonInput(self, jsonInput): #show our input in the log print(jsonInput) #map our passed values to our input placeholders feed_dict = {self.a: jsonInput['a'], self.b: jsonInput['b']} #run the calculation and obtain a result rawResult = self.sess.run(self.c,feed_dict) #convert to array and embed the answer as 'c' field in a python object return {'c':rawResult.tolist()} #custom function to change the operation type def changeOperation(self, type): if(type == '+'): self.c = self.a + self.b elif(type == '-'): self.c = self.a - self.b #expected optional api: We don't do any training in this example def onBeginTraining(self): pass #NOTE: this is a module function, not a class function. Change your CLASSNAME to reflect your class #required function to get our api def getApi(): #return CLASSNAME.getInstance() return ExampleAPI.getInstance() ``` A full example using mnist can be seen here: https://github.com/getnamo/TensorFlow-Unreal-examples/blob/master/Content/Scripts/mnistSimple.py A full example using save/load setup can be seen here: https://github.com/getnamo/TensorFlow-Unreal-examples/blob/master/Content/Scripts/mnistSaveLoad.py Another full example using keras api can be found here: https://github.com/getnamo/TensorFlow-Unreal-examples/blob/master/Content/Scripts/mnistKerasCNN.py. Note the keras callback used for stopping training after current batch completes, this cancels training on early gameplay exit e.g. EndPlay. #### Asynchronous Events to Tensorflow Component If you need to stream some data to blueprint e.g. during training you can use the ```self.callEvent()``` api. ##### String Format The format is ```self.callEvent('EventName', 'MyString')``` ##### Json Format The format is ```self.callEvent('EventName', PythonObject, True)``` Example use case in [mnistSpawnSamples.py](https://github.com/getnamo/TensorFlow-Unreal-examples/raw/master/Content/Scripts/mnistSpawnSamples.py#L87) where sample training images are emitted to unreal for preview. ## Blueprint API ### Load your python module from your TensorflowComponent Once you've [written your python module](https://github.com/getnamo/TensorFlow-Unreal#mysubclasstfpluginapi), Select your TensorflowComponent inside your actor blueprint ![select component](https://camo.githubusercontent.com/7ad5402dc1bf1e7b62a7dbb5a4a21f16fc1efe41e9302a3e49c93abb138a249d/687474703a2f2f692e696d6775722e636f6d2f66395379716c312e706e67) and change the TensorFlowModule name to reflect your _filename_ without .py. e.g. if my python file is _ExampleAPI.py_ it would look like this ![change module name](https://camo.githubusercontent.com/fd46197c972e45ba1cf918be912773f606f3e590b6d108667ddb4bb633eaeaf9/687474703a2f2f692e696d6775722e636f6d2f6d707a796d67642e706e67) Optionally disable the verbose python log and change other toggles such as training on _BeginPlay_ or disabling multithreading (not recommended). ### Training By default the _onBeginTraining()_ function will get called on the component's begin play call. You can optionally untick this option and call _Begin Training_ manually. ![manual train](https://camo.githubusercontent.com/b15f8d3bbbd7212b2f5665d6d4afb308a910eaeecb31365161033d1dd222134b/687474703a2f2f692e696d6775722e636f6d2f594d334b5a77792e706e67) ### Sending Json inputs to your model for e.g. prediction You control what type of data you forward to your python module and the only limitation for the current api is that it should be JSON formatted. #### Basic Json String In the simplest case you can send e.g. a basic json string ```{"MyString","SomeValue"}``` constructed using SIOJson like so ![send json string](https://camo.githubusercontent.com/fa44dd8477d3737ab0b682b3cd954f09cd9e952ec5ee55f5608769ff5ee5da36/687474703a2f2f692e696d6775722e636f6d2f78697a427270742e706e67) #### Any UStruct Example SIOJson supports completely user defined structs, even ones only defined in blueprint. It's highly recommended to use such structs for a convenient way to organize your data and to reliably decode it on the python side. Below is an example where we send a custom bp struct and encode it straight to JSON. ![send custom struct](https://camo.githubusercontent.com/ccf69950a1a56f7f7708110aacda996ee3c9c85dba9b64c5ce06660ab7cee14e/687474703a2f2f692e696d6775722e636f6d2f4f766132787a662e706e67) with the struct defined in blueprint as ![custom struct definition](https://camo.githubusercontent.com/49cd6211e941f826c260ce8aa1f1cf45daa21d4dbde27052d6a87c805b2093a2/687474703a2f2f692e696d6775722e636f6d2f686733716c534b2e706e67) You can also interweave structs, even common unreal types so feel free to mix and match both of the above methods. In this particular example we interweave a 3D vector in a json object we defined. The sent input should now be ```{"SomeVector":{"x":1.0,"y":2.3,"z":4.3}}``` ![send struct](https://camo.githubusercontent.com/6edd4fdeb73fc7143918eec216a6421c9feed05536fd1299ba42fffa031f7e34/687474703a2f2f692e696d6775722e636f6d2f4e4a34384d37302e706e67) #### Special convenience case: UTexture2D A convenience function wraps a UTexture2D into a json object with ```{"pixels":[<1D array of pixels>], "size":{"x":,:"y":}}``` which you can reshape using numpy. ![send texture](https://camo.githubusercontent.com/dbdd0ec40fe8b7366ad9d5397ce094f4dfac71491f0cdbed9761ac93db2ce5f6/687474703a2f2f692e696d6775722e636f6d2f765371327865612e706e67) Note that this currently will convert an image into full alpha greyscale. If you need color texture inputs, use own custom method or make a pull request. #### Custom functions If you need to call python functions from blueprint which the current api doesn't support, you can do so by using the ```CallCustomFunction``` method on the _TensorflowComponent_. You specify the function name and pass in a string as arguments. The function runs on the game thread and will return immediately with an expected string value. For both arguments and returning values, JSON encoding is recommended, but optional. ![custom function call](https://camo.githubusercontent.com/2f163062bdcdd53c533d6baab691b554555fb5b70b8463b6398cd0186cdf6c7e/687474703a2f2f692e696d6775722e636f6d2f656a42733863492e706e67) Example custom function call passing in a string argument to [```changeOperation```](https://github.com/getnamo/TensorFlow-Unreal-examples/raw/master/Content/Scripts/addExample.py#L31) in [addExample.py](https://github.com/getnamo/TensorFlow-Unreal-examples/raw/master/Content/Scripts/addExample.py) ### Handling Tensorflow Events Select your _Tensorflow Component_ from your actor blueprint and then click + to subscribe to the chosen event in the event graph. ![events](https://camo.githubusercontent.com/3d5563e8fd29b4bf325da89f9d36a696e5953ea8edbc140701c109eef900da95/687474703a2f2f692e696d6775722e636f6d2f3271373438366b2e706e67) current api supports the following events #### On Input Results Called when _onJsonInput()_ completes in your python module. The returned data is a json string of the return data you pass at the end of the function. ![onresults](https://camo.githubusercontent.com/34707932d0ef0d7aaa12580e7e348463328c76b04d6dbcf74f1fdb95cbaa8f32/687474703a2f2f692e696d6775722e636f6d2f6c4c62746d56742e706e67) Normally you'd want to convert this string into _SIOJsonObject_ so you can use your results data in blueprint. It is also typical to have a prediction field attached to this object for e.g. classification tasks. If you have a regular return format, consider making your own custom bp struct and fill its value from the json string like this ![fill struct from json](https://camo.githubusercontent.com/53d71edfcacfe5b19475e40c27705f2a1b37c555fec00a826b6154c35f14cebc/687474703a2f2f692e696d6775722e636f6d2f494257597a77392e706e67) Note that the function will only fill fields that have matching names and ignore all other struct fields. This means you can safely fill a partial struct from a json string that has more fields than the struct defines. #### On Training Complete When the _onBeginTraining()_ call is complete you receive this event with ```{'elapsed':}``` json, optionally with additional return data passed in from your function. ![ontraining](https://camo.githubusercontent.com/5eef2d8254dd22d10a578ecc36a7036e29a3582f715b31d69ce497caa651524d/687474703a2f2f692e696d6775722e636f6d2f58695a684830342e706e67) #### On Event If you use [```self.callEvent()```](https://github.com/getnamo/TensorFlow-Unreal#asynchronous-events-to-tensorflow-component) you will receive this event dispatch. You can filter your event types by the event name and then do whatever you need to with the data passed in. ![onevent](https://camo.githubusercontent.com/8088c7038ae279f9930111db9ff7f4ec7f8ebc8abd5928a2b80ed46a2c445964/687474703a2f2f692e696d6775722e636f6d2f6e793061455a762e706e67) For example [mnistSpawnSamples.py](https://github.com/getnamo/TensorFlow-Unreal-examples/raw/master/Content/Scripts/mnistSpawnSamples.py#L121) uses ```self.callEvent()``` to async stream training images and we'd filter this via checking for ```'PixelEvent'``` ## Blueprint Utilities ### Conversion A large portion of the plugin capability comes from its ability to convert data types. See [TensorflowBlueprintLibrary.h](https://github.com/getnamo/TensorFlow-Unreal/raw/master/Source/TensorFlow/Public/TensorFlowBlueprintLibrary.h) for full declarations and code comments. #### UTexture2D to float array (grayscale) Convert a UTexture2D as grayscale to a 1D float array; obtains size from texture. _Blueprint_ ``` ToGrayScaleFloatArray (Texture2D) ``` _C++_ ```c++ static TArray Conv_GreyScaleTexture2DToFloatArray(UTexture2D* InTexture); ``` #### UTexture2D to float array Convert a UTexture2D to a 1D float array; obtains size from texture. Expects 4 1-byte values per pixel e.g. RGBA. _Blueprint_ ``` ToFloatArray (Texture2D) ``` _C++_ ```c++ static TArray Conv_Texture2DToFloatArray(UTexture2D* InTexture); ``` #### Invert Float Array Invert values in a given float array (1->0, 0->1) on a 0-1 scale. _Blueprint_ ``` InvertFloatArray ``` _C++_ ```c++ static TArray InvertFloatArray(const TArray& InFloatArray); ``` #### Float array to UTexture2D Convert a 4 value per pixel float array to a UTexture2D with specified size, if size is unknown (0,0), it will assume a square array. _Blueprint_ ``` ToTexture2D (Float Array) ``` _C++_ ```c++ static UTexture2D* Conv_FloatArrayToTexture2D(const TArray& InFloatArray, const FVector2D Size = FVector2D(0,0)); ``` #### Float array (Grayscale) to UTexture2D Convert a 1 value per pixel float array to a UTexture2D with specified size, if size is unknown (0,0), it will assume a square array. _Blueprint_ ``` ToTexture2D (Grayscale Array) ``` _C++_ ```c++ static UTexture2D* Conv_FloatArrayToTexture2D(const TArray& InFloatArray, const FVector2D Size = FVector2D(0,0)); ``` #### ToTexture2D (Render Target 2D) Convert a UTextureRenderTarget2D to a UTexture2D _Blueprint_ ``` ToTexture2D (Render Target 2D) ``` _C++_ ```c++ static UTexture2D* Conv_RenderTargetTextureToTexture2D(UTextureRenderTarget2D* InTexture); ``` #### ToFloatArray (bytes) Convert a byte array into a float array, normalized by the passed in scale _Blueprint_ ``` ToFloatArray (bytes) ``` _C++_ ```c++ static TArray Conv_ByteToFloatArray(const TArray& InByteArray, float Scale = 1.f); ``` ## TF Audio Capture Component A c++ component that uses windows api to capture and stream microphone audio without the need of an online subsystem. See https://github.com/getnamo/TensorFlow-Unreal/blob/master/Source/TFAudioCapture/Public/TFAudioCaptureComponent.h for details on API. This component is aimed to be used for native speech recognition when Tensorflow examples mature. ## File Utility Component A simple blueprint wrapper to save and load bytes from file. Allows to easily flush e.g. audio capture for later use. See https://github.com/getnamo/TensorFlow-Unreal/blob/master/Source/CoreUtility/Public/FileUtilityComponent.h for details on API. ## Use pip to manage your dependencies in the python console The plugin uses a pip wrapper script that uses a subproccess to not cause blocking behavior. Simply import it using ```import upypip as pip``` in your script and then type e.g. ```pip.list()``` which should very shortly list all your installed python modules. ``` Package Version -------------- --------- absl-py 0.1.10 astor 0.6.2 bleach 1.5.0 gast 0.2.0 grpcio 1.10.0 html5lib 0.9999999 Markdown 2.6.11 numpy 1.14.1 pip 9.0.1 protobuf 3.5.1 setuptools 38.5.1 six 1.11.0 tensorboard 1.6.0 tensorflow 1.6.0 tensorflow-gpu 1.6.0 termcolor 1.1.0 Werkzeug 0.14.1 wheel 0.30.0 ``` If you'd like to add another module call the install function e.g. if you wanted to upgrade to gpu version you could simply type ```pip.install('tensorflow-gpu')``` or you can go back to a clean slate with ```pip.uninstallAll()``` which should leave you with just the basics ``` Package Version ---------- ------- pip 9.0.1 setuptools 38.5.1 wheel 0.30.0 ``` See [upypip.py](https://github.com/getnamo/UnrealEnginePython/raw/master/Content/Scripts/upypip.py) for all the available commands. ## Note on Dependencies Depends on an [UnrealEnginePython](https://github.com/getnamo/UnrealEnginePython) plugin fork and the [SocketIO Client](https://github.com/getnamo/socketio-client-ue4) plugin. Both of these and an embedded python build are included in every [release](https://github.com/getnamo/TensorFlow-Unreal/releases) so you don't need to manually include anything, just drag and drop the *Plugins* folder into your project from any release. ### Architecture and Purpose ![architecture](https://camo.githubusercontent.com/030e72283c1a9332977c69d42cc6e1799e7ecfd141f805108a2e6f84fba5dd8b/687474703a2f2f692e696d6775722e636f6d2f3862556943624d2e706e67) #### UnrealEnginePython Based on the wonderful work by [20tab](https://github.com/20tab/UnrealEnginePython), the UnrealEnginePython plugin fork contains changes to enable multi-threading, python script plugin encapsulation and automatic dependency resolution via pip. Simply specifying tensorflow as a _pythonModule_ dependency in https://github.com/getnamo/TensorFlow-Unreal/blob/master/Content/Scripts/upymodule.json makes the editor auto-resolve the dependency on first run. The multi-threading support contains a callback system allowing long duration operations to happen on a background thread (e.g. training) and then receiving callbacks on your game-thread. This enables TensorFlow to work without noticeably impacting the game thread. #### SocketIO Client SocketIO Client is used for easy conversion between native engine types (BP or C++ structs and variables) and python objects via JSON. Can optionally be used to connect to a real-time web service via [socket.io](https://socket.io/). ## Packaging #### Note on Blueprint Only projects You will need to convert your blueprint only project to mixed (bp and C++) before packaging. Follow these instructions to do that: https://allarsblog.com/2015/11/04/converting-bp-project-to-cpp/ #### Extra step Since v0.10.0 the plugin should package correctly, but will require to run the packaged build once to pull the dependencies. You can optionally manually copy them from ```{Project Root}/Plugins/UnrealEnginePython/Binaries/Win64/Lib/site-packages``` to the packaged folder to ```{Packaged Root}/{Project Name}/Plugins/UnrealEnginePython/Binaries/Win64/Lib/site-packages```. When you first launch your packaged project there may be a black screen for a while (2min) as it reinstalls pip and _pulls the dependencies_ for the first time. You can then reload the map after a few minutes or just restart (check your packaged log to see when it's ready). Each time after that the project should load quickly. Note that you can zip up and move the packaged project to another computer with all the dependencies, but it will have ~20sec boot up on first run as it re-installs pip to the correct location, but it won't have to pull the pip dependencies saving most of the waiting and then quick bootup each time after that. ## Troubleshooting / Help ### I see pip errors from upgrading tensorflow version Delete ```Plugins\UnrealEnginePython\Binaries\Win64\Lib\site-packages``` and restart project ### No module named 'tensorflow' On first run you may see this message in your python console ![no tensorflow](https://camo.githubusercontent.com/bc8d76fbff15d1442c30d7a9f7ff887585124149db384731003fcadc5bdb779f/687474703a2f2f692e696d6775722e636f6d2f6f6564384868712e706e67) Wait until pip installs your dependencies fully, this may take ~3-5min. When the dependencies have installed, it should look something like this ![installed](https://camo.githubusercontent.com/d1f44820711995dfff9176db880b8a185242b5528cd6e0bc55dd0d0683c385e0/687474703a2f2f692e696d6775722e636f6d2f7338574475374d2e706e67) After you see this, go ahead and close your editor and re-launch the project. When the project has launched again this error should not show up again. ### 2-3 sec hitch on first begin play This is due to python importing tensorflow on begin play and loading all the dlls. Currently unavoidable, only happens once per editor launch. ### Issue not listed? Post your issue to https://github.com/getnamo/TensorFlow-Unreal/issues ## [License](https://github.com/getnamo/TensorFlow-Unreal/raw/master/LICENSE) Plugin - [MIT](https://opensource.org/licenses/MIT) TensorFlow and TensorFlow Icon - [Apache 2.0](http://www.apache.org/licenses/LICENSE-2.0)
