# Midi-Unreal Midi for Unreal Engine Discord: https://discord.gg/yR5wYkX MarketPlace: https://www.unrealengine.com/marketplace/procedural-midi
Example Project: Updated 2/27/2017
This code provides an interface to read, manipulate, and write MIDI files. "Playback" is supported as a real-time event dispatch system.(Leffelman) Original Credit goes to Alex Leffelman who created the Android Midi Lib - https://github.com/leffelmania/android-midi-lib Modified for Unreal Engine: Scott Bishel http://groundsthirteen.webs.com/midi.htm - libraries for c++/c#/obj-c Features: - Ability to import [drag & drop] Midi files in Unreal - Load/Play Midi - Built in Midi Device Interface - Choice between MIDI output device (ex. computer, synthesizer, etc) or generated audio playback [**] - Ability to connect external MIDI input device (ex. Midi Keyboard, Midi Fighter 64, any MIDI-equipped hardware) [**] [Sending MIDI to/from another program or VST] is possible with a virtual MIDI driver. LoopMidi
--By sending midi data to the virtual midi device...you can have other apps be able to retrieve that data
-You can interact with the midi device by using the Midi Interface Component
** [Shown in Demo Project on marketplace] Plugin Build Supports: - Windows(32/64): [Packaged+Tested+Works] - HTML5: [Packaged+Tested+Works] - Android(All): [Packaged+Tested+Works] - Linus: [Packaged+Tested+Works] - Mac/IOS: [Packaged+Tested+Works] ### Installation \[Github Version Only / C++ Project Required\] [Caution: careful when you have marketplace and c++ plugins on same UE version as they may conflict with eachother] Place MidiAsset folder in your Plugins folder in youe Unreal project ###Showcase: [Blueprint] ![ScreenShot](https://github.com/Geromatic/Midi-Unreal/raw/main/Feature/Midi_Screenshot_Overview.PNG) ![ScreenShot](https://github.com/Geromatic/Midi-Unreal/raw/main/Feature/Midi_Screenshot_Preview.png) ![ScreenShot](https://github.com/Geromatic/Midi-Unreal/raw/main/Feature/Midi_Screenshot_Detail.PNG) ![ScreenShot](https://github.com/Geromatic/Midi-Unreal/raw/main/Feature/Midi_Screenshot_Info.PNG) ![ScreenShot](https://github.com/Geromatic/Midi-Unreal/raw/main/Feature/Midi_Screenshot_Library.PNG) ###Example Usage: [Beta-Untested/C++] ---- ```c++ // headers #include // std::vector #include // std::cout, std::ostream, std::ios, std::streambuf #include // std::filebuf using namespace std; // optional ``` #### Reading and Writing a MIDI file: ```c++ struct membuf : std::streambuf { membuf(char* begin, char* end) { this->setg(begin, begin, end); } }; FString path; TArray data; bool result = FFileHelper::LoadFileToArray(data, path.GetCharArray().GetData()); if (result == 0 || data.Num() == 0) return; char* ptr = (char*)data.GetData(); membuf sbuf(ptr, ptr + data.Num()); std::istream in(&sbuf); MidiFile midi(in); ... std::filebuf fb; fb.open("test.txt", std::ios::out); std::ostream os(&fb); midi.writeToFile(os); ``` #### Manipulating a MIDI file's data: Removing a track: ```c++ midi.removeTrack(2); ``` Removing any event that is not a note from track 1: ```c++ MidiTrack& track = *midi.getTracks()[1]; std::vector::iterator it = track.getEvents().begin(); std::vector eventsToRemove; while (it) { MidiEvent* _event = *it; if (!(_event->getType() == ChannelEvent::NOTE_ON) && !(_event->getType() == ChannelEvent::NOTE_OFF)) { eventsToRemove.Add(_event); } it++; } for (int i = 0; i < eventsToRemove.Num(); i++) { track.removeEvent(eventsToRemove[i]); } ``` Reducing the tempo by half: ```c++ MidiTrack& track = *midi.getTracks()[0]; std::vector::iterator it = track.getEvents().begin(); while (it) { MidiEvent* _event = *it; if (_event->getType() == MetaEvent::TEMPO) { Tempo* tempoEvent = (Tempo*)_event; tempoEvent->setBpm(tempoEvent->getBpm() / 2); } it++; } ``` #### Composing a new MIDI file: ```c++ // 1. Create some MidiTracks MidiTrack& tempoTrack = *new MidiTrack(); MidiTrack& noteTrack = *new MidiTrack(); // 2. Add events to the tracks // Track 0 is the tempo map TimeSignature& ts = *new TimeSignature(); ts.setTimeSignature(4, 4, TimeSignature::DEFAULT_METER, TimeSignature::DEFAULT_DIVISION); Tempo& tempo = *new Tempo(); tempo.setBpm(228); tempoTrack.insertEvent(&ts); tempoTrack.insertEvent(&tempo); // Track 1 will have some notes in it const int NOTE_COUNT = 80; for(int i = 0; i < NOTE_COUNT; i++) { int channel = 0; int pitch = 1 + i; int velocity = 100; long tick = i * 480; long duration = 120; noteTrack.insertNote(channel, pitch, velocity, tick, duration); } // 3. Create a MidiFile with the tracks we created std::vector& tracks = *new std::vector(); tracks.push_back(&tempoTrack); tracks.push_back(¬eTrack); MidiFile& midi = *new MidiFile(MidiFile::DEFAULT_RESOLUTION, tracks); // 4. Write the MIDI data to a file std::filebuf fb; fb.open("test.txt", std::ios::out); std::ostream os(&fb); midi.writeToFile(os); ``` #### Listening for and processing MIDI events ```c++ // Create a new MidiProcessor: MidiProcessor processor; processor.load(midi); // Register for the events you're interested in: EventPrinter ep; processor.setListener(&ep); // Start the processor: processor.start(); ``` ```c++ // This class will print any event it receives to the console class EventPrinter: public MidiEventListener { public: EventPrinter() { } void onStart(bool fromBeginning) { if(fromBeginning) { UE_LOG(LogTemp, Display, TEXT("Started!")); } else { UE_LOG(LogTemp, Display, TEXT("Resumed!")); } } void onEvent(MidiEvent* _event, long ms, int trackID) { FString layerName(_event->toString().c_str()); UE_LOG(LogTemp, Display, TEXT("received event: %s"), *layerName); } void onStop(bool finished) { if(finished) { UE_LOG(LogTemp, Display, TEXT("Finished!")); } else { UE_LOG(LogTemp, Display, TEXT("Paused!")); } } }; ```
